Graphical Plant View

The Graphical Plant View is view of the Plant (User-Designed via the Workflow Editor) that shows the loading generated by the Constraint Scheduling Process.   The Graphical Plant View is linked to the generated Workflow in Requirements>Settings>Requirement Rules

Selection Options

Schedule: Select either Planned or Firm from the drop-down list

(Selection Period): Select either Date or Week Start from the drop-down list to select the time span

(Date): Select the date for the display.  For Week Start (above) this denotes the first date in the week

Buttons

Close: Exits this screen
